Product Description
The Best Relation of Quality and Price in the Global Market..!
Divided 2 in 1 parts: a hot part for pasteurizing
and a cold part for batch freezing,
they can work at same time or separately.
Hardness-control-system (HCS)
integrated with experienced technology
availablefor any operator to make
the same high-quality gelato.
Fully automatic operation with
very friendly and flexible interface.
Patent dasher with high performance,
easy to clean and replace.
Vertical heating tub with
fluent transfer tube,
easy for operating, cleaning
and maintenance.
Unique designed evaporator with gas finely
dispersed to “Multipoint” around cylinder.
Two speeds, low for Italian gelato and
high for high overrun ice cream.
Designed with safety devices to protect the
operator and the machine from dangers.
Practical built-in water hose allowing
easier and faster cleaning.
Maximum extraction resulting in
minimal flavors overlap.
Automatic audible alarm signals
when a process is done.
International acceptable
R404a refrigerate gas.
This machine is divided into
two parts, the hot part works
for pasteurizing and the cold
part for batch freezing.
They can work at same time which
makes the machine have the
characteristic of operating quickly,
simply and saving space.
It is adopted the most advanced
freezing cylinder design of the world
and promoted dasher.
Meanwhile it is assembled
the technical grade
frequency converter which can save the energy,
start and stop very quietly and help to extend
the working life of the compressor
and churning motor.
It is allocated with the French Tecumesh
compressor cooling system
and American Sporlan expansion valve, etc.
The warranty period of the imported
compressor and the parts is 3 years
and the warranty period of the
whole machine is 1 year.
Features Include:
1. The whole machine is controlled by
the computer intelligent system
with large LCD screen. The machine operating
status is shown in the graphics
whose interface can reflect the communication
between the operator and the machine.
The preference was protected by the password
which can prevent the operation by mistake.
2. Quantized and selective
automatic control system.
3. Output is adopted the low noise
and undisturbed technology.
4. The Vertical and fluent
transfer tube heating kettle,
easy for operating,
cleaning and maintenance.
5. The high efficient evaporator construction
and the multipoint linear
heat-conducting control
can batch freeze very fast.
6. Three phrases stainless steel dasher with module
design scrape the materials thoroughly.
And it can be discharged conveniently
and cleaned easily.
7. High impact extrusion technology
avoids the mix of different flavors.
8. There are many security modules and
self trouble diagnosis system inside.
9. Humanistic slant control faceplate.
10.Closed cleaning water source help
to work efficiently and sanitarily.
11.Adpoting the UFI approved
environmental-friendly refrigerant R404A
Most of the main spare parts for our machines are imported
from the world famous companies.
Easy to operate! Easy to clean! Easy to maintain!
Technical Features
Item Model: ARTISAN COMPO AW2040
Main Power: 220/380V-50/60Hz
Rated Power: 8.65 Kw
Gas Type: R404A
Hourly output: 20-40 L
Mixing Cylinder Capacity: 10 Liter
Heating Cylinder Capacity: 8 Liter
Water or Air Cooling
Net Weight: 215Kg
Time to finisch one batch 6-15 Min.
Dimension: 520 x 520 x 1300
Stainless Steel Stantard:
AISI Type 304
Our batch freezer equipment testing for many years in
several European countries in Italian,German Ice Cream Shops,
with the best recommendations. .
Terms and conditions
Delivery time : 2-5 weeks upon receipt of payment,
depends on the quantity and the additional function.
A standard spare part is posted within 24 hours
of ordering and reaches
its destination in 2–3 days.
